• Intel® Xeon ® processor E5-2600 or E5-2600v2 product family

  Processor Socket:
  2

  Internal Interconnect:
  2 x Intel Quick Path Interconnect (QPI) links: 6.4 GT/s, 7.2 GT/s, 8.0 GT/s

  Cache:
  2.5MB per core; core options: 4, 6, 8, 10, 12

• Microsoft® Windows Server® 2012
  Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V®)
  Novell® SUSE® Linux Enterprise Server
  Red Hat® Enterprise Linux®
  Virtualization options:
  Citrix® XenServer®
  VMware® vSphere® ESXi ™
  Red Hat Enterprise Virtualization®

• Intel C602

• Up to 768GB (24 DIMM slots) 2GB/4GB/8GB/16GB/32GB DDR3 up to 1866MT/s

• Maximum internal storage:
  Up to 10TB

  Hot-plug hard drive options:
  2.5” PCIe SSD, SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K), SAS 512e (15K)
  Self-Encrypting Drives available

• Up to ten 2.5" hot-plug SAS, SATA, or SSD or up to four hot-plug 2.5" SAS, SATA, or SSD + two PCIe SSD

• 3 PCIe slots:
  Two x16 slots with x16 bandwidth, half-height, half-length
  One x16 slot with x8 bandwidth, half-height, half-length
  (ten-drive-bay configuration is available only with 3 PCIe slot option)

  or

  2 PCIe slots:
  One x16 slot with x16 bandwidth, full-height, 3/4 length
  One x16 slot with x16 bandwidth (or x8 with one processor only), half-height, half-length

• Internal controllers:
  PERC S110 (SW RAID)
  PERC H310
  PERC H710
  PERC H710P
  External HBAs (RAID):
  PERC H810
  External HBAs (non-RAID):
  6Gbps SAS HBA

• Broadcom® 5720 quad-port 1GbE Base-T (no TOE or iSCSI offload)
  Intel I350 quad-port 1GbE Base-T (no TOE or iSCSI offload)
  Intel X540 dual-port 10GbE Base-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports)
  Broadcom 57800S dual-port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports) Broadcom 57800S dual-port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)Broadcom 57840S quad-port 10GbE SFP+ Rack NDC (NPAR1.0, SRIOV, DCB, iSCSI and FCoE offloads and CEM)

• Titanium efficiency, hot-plug redundant 750W power supply
  Platinum efficiency, hot-plug redundant 495W, 750W or 1100W power supplies
  Auto-ranging power supplies

• High-efficiency, hot-plug, redundant power supplies; DC power supplies; hot-plug hard drives; TPM; dual internal SD support; hot-plug redundant fans; optional bezel; luggage-tag; ECC memory; interactive LCD screen; extended thermal support; ENERGY STAR® compliant; extended power range; Switch Agnostic Partitioning (SWAP)

• Remote Management
  iDRAC7 with Lifecycle Controller
  iDRAC7 Express (default), iDRAC7 Enterprise (upgrade option),
  8GB vFlash media (upgrade option), 16GB vFlash media (upgrade option)

  Systems Management
  IPMI 2.0 compliant
  Dell OpenManage™ Essentials
  Dell OpenManage Power Center
  Dell OpenManage Connections:
  • Dell OpenManage Integration Suite for Microsoft® System Center
  • Dell plug-in for VMware® vCenter™
  HP Operations Manager, IBM Tivoli® Netcool® , and CA Network and Systems Management

• ReadyRails II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
  ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks.
